T1 Tillett W4

THE W4 – CAR SEAT

The W4 has been designed predominately for those drivers wishing to lay down at a formula car driving angle. This wider XL version of the W3 is most suited to people over 100kg. The W4 measures 46.5cm at the external widest point of its outer rolled edge.

Low profile seatbelt harness holes are included, enabling use of a five or six point harness. A crotch strap is strongly recommended with any reclined seat.

The low back W models are most suitable when a headrest is not practical, maybe for an application where there is already a headrest support in existence.

The weight of a W4 with the backframe is approximately 3.6kg and 2kg without.

The W4 has a gloss black GRP front surface with the additional option of a two-panel set of Dinamica® suede covered pads.

The W4 is available as a single skin shell, or with a floor mountable backframe with four captive M8 fittings in the base or with side mounts.

Available with no seat inserts, black suede inserts, or silver diamond stitched inserts.

There are currently tariffs on all Tillett parts which will be assessed once an order is processed. We will reach out before the order is fully processed to confirm the tariff rates and get approval.

KEY FEATURES

• Most reclined Tillett seat for larger drivers
• 25mm wider than the W3 – great for drivers over 100kg
• Body mirroring shape for full support and comfort
• Approximately 2kg without backframe, 3.6kg with backframe
• Low profile harness holes for 5 or 6 point harness
• Available with bonded composite backframe (base mount or side mount)
• One finish: black gloss GRP front
• Manufactured in the United Kingdom

COMPATIBLE SEAT BRACKETS

• STBI Bracket Set
